Cisco Catalyst C9500-40X-E40-port 10Gig switch Network Essentials
Stok Durumu:
Stokta kalmasa da sipariş verilebilir
- Product Code :C9500-40X-E
- Description :Catalyst 9500 40-port 10Gig switch, Network Essentials
- Switching capacity:Up to 480 Gbps full duplex
- Forwarding rate:Up to 720 Mpps
- AC power max rating: 950W
- System power consumption:850W max
Product Specification
Switching capacity:
Up to 480 Gbps full duplex
50 to 60 Hz
Input Voltage:
AC 115 to 230 VAC
RAM:
16 GB
Ports:
40
Power Supply:
950W
Dimension:
1.73 x 17.5 x 21.52 in
Max. Power Consumption:
850W max
Overview (C9500-40X-E)
C9500-40X-E is one of the the Cisco Catalyst 9500 Series Switches. The Cisco Catalyst 9500 Series Switches are the next generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on an x86 CPU, the Catalyst 9500 Series is Cisco’s lead purpose-built fixed core and aggregation enterprise switching platform, built for security, IoT, and cloud. The Catalyst 9500 Series is the industry’s first purpose-built 40 Gigabit Ethernet line of switches targeted for the enterprise campus.
QUICK SPECS
Table 1 shows the Quick Specs.
| Product Code | C9500-40X-E |
| Description | Catalyst 9500 40-port 10Gig switch, Network Essentials |
| Switching capacity | Up to 480 Gbps full duplex |
| Forwarding rate | Up to 720 Mpps |
| AC power max rating | 950W |
| System power consumption | 850W max |
| Dimensions (H x W x D) | 1.73 x 17.5 x 21.52 in |
| Rack units (RU) | 1 RU |
PRODUCT DETAILS
Figure 2 shows the front panel of C9500-40X-E.
Note:
| ① | 40 10G SFP ports |
| ② | Network modules |
| ③ | RFID |
| ④ | Console port (RJ-45 Serial) |
| ⑤ | Blue beacon LED |
| ⑥ | USB mini Type B console port |
| ⑦ | Mode button |
| ⑧ | USB 2.0 host port |
| ⑨ | Ethernet management RJ-45 port |
